NF-DAR
Leakage Current Reduction Filter
Especially for systems with RCCB 30 mA / 300 mA
To suppress undesirable leakage currents ≥ 2kHz
Supports the effect of existing EMC filter
Suitable for frequency inverters and servo drives with long motor cable
Without Y capacitor (no leakage current)
Fingerproof terminals
Current rating 10 A – 180 A
NF-KC-DAR
EMC Filter + Leakage Current Reduction Filter in one
Especially for systems with RCCB 30 mA / 300 mA
To suppress undesirable leakage currents ≥ 2kHz
Combines EMC- and Leakage Current Reduction Filter
Comliance with the limits acc. to IEC/EN 61800-3 Kat. C1 / C2
Suitable for frequency inverters and servo drives with long motor cable
High saturation resistance
Low leakage current
Fingerproof terminals
Current rating 10 A – 180 A
Leakage Current Reduction Filters
